Products

Noiseken ESD Simulators Noiseken Discharge Resistors and Capacitor Units for TC-815 ESD Guns

In Stock

The EMC Shop has an assortment of Noiseken Resistance/Capacitance combinations available as a lot. Inquire for pricing.

Read more less

In Stock

$0.00

Noiseken ESD Simulators Noiseken ESS-2000 30kV Electrostatic Discharge Gun

In Stock

The Noiseken ESS-2000 simulator is a popular among car manufacturers such as Honda and Toyota for ISO 10605 ESD Testing. The ESS-2000 provides four operation modes, allowing the operator to conduct a single step testing for the IEC specified test voltages and for a series of stored test settings. Noiseken ESS-2000 Features: Meets and far exceeds the requirements in EN/IEC61000-4-2 Up to 30kV output in both contact and air discharges A light weight discharge gun Easily changeable capacitor and resistor units A wide range of options CE marked Controllable from an external computer using various communication interfaces.

Read more less

In Stock

$1,195.00

View options

Noiseken ESS-2000 30kV Electrostatic Discharge (ESD) Gun

Noiseken ESD Simulators Noiseken ESS-200AX 30kV Electrostatic Discharge ESD Simulator

In Stock

The Noiseken ESS-200AX 30kV ESD electrostatic simulator was a very popular unit but has been discontinued by the manufacturer. Current models are the ESS-B3011 and ESS-S3011. The ESS-200AX is still suitable for precompliance testing to IEC/EN 61000-4-2 or general test and debugging for ESD immunity. Noiseken ESS-200AX Features: 0.20 - 30kV Output Voltage Discharge Interval Programmable from 0.05 to 600 seconds Pre programmed IEC Severity Levels Storage functionality in Manual, Sweep and Program Mode

Read more less

In Stock

$6,950.00

Noiseken ESD Simulators NoiseKen ESS-6002 Component Level Electrostatic Discharge Simulator

In Stock

The NoiseKen ESS-6002 Component Level Electrostatic Discharge Simulator is a tester specifically designed to carry out ESD sensitivity testing of semiconductor devices to standards such as MIL-STD-883, EIAJ ED-4701 and others. Included are the Human Body Model (HBM) and Machine Model (MM) probes. As a DUT interface, select either Free Type Probe Stand where virtually any package type can be connected by means of a pair of miniature test leads or Semi-automatic Precision Type Probe Stand providing automatic and precise pin-to-pin feeding with a minimum 0.01mm resolution. Meets Human Body Model (HBM) Compliance Standards: AEC-Q100-002-Rev.D Jul.2003 ESDA ANSI/EOS/ESD-STM5.1-2001 IEC 61340-3-1Ed.1.0 2002 IEC 60749-26 Ed.1.0 2003 JEDEC JESD22-A114E Jan 2007 JEITA EIAJ ED-4701/300 Aug.2001 Test Method304 MIL-STD-883G Method 3015.7 Mar.1989 Meets Machine Model (MM) Compliance Standards: AEC-Q100-003-REV-E Jul.2003 ESDA ANSI/ESD STM5.2-1999 IEC 61340-3-2 Ed.1.0-2002 IEC 60749-27 Ed.1.0 2003 JEDEC JESD22-A115A Oct.1997 JEITA EIAJ ED-4701/300 Aug.2001 NoiseKen ESS-6002 Features: 10V minimum output (1V step) A simple probe stand and test fixture plus a pair of miniature test leads meeting many different kinds of device packages <Free Board Type> Narrow pitch DUT can be tested in semi-automatic manner <Semi-automatic Precision Type> Each probe has a coaxial interface with an external measuring instrument. External trigger input and output terminals are provided.

Read more less

In Stock

$19,750.00

Noiseken ESS-B3011 ESD Simulation Test Equipment & GT-30R ESD Pistol - ESDGuns.com

Noiseken GT-30R ESD Dischage Pistol Illuminates Discharge Points for Better Visual Observation

Noiseken ESD Simulators Noiseken ESS-B3011 ESD Simulation Test Equipment & GT-30R ESD Pistol

In Stock

The Noiseken ESS-B3011 & GT-30R ESD test equipment is a cost-oriented basic model ESD Simulator with a light weight discharge gun pistol attachable. The 30 kV output voltage makes this unit suitable for EN/IEC61000-4-2 and the ISO 10605 standard. The Noiseken GT-30R discharge gun has been renewed completely to materialize much more lightning and best gravity balance. Human load in the operation can be remarkably reduced comparing to the previous model. Electrostatic discharge can be confirmed with LED light on the body in this new discharge gun. Noiseken ESS-B3011 & GT-30R Features: “Pre-checking function” taking the confirmable test into the account “Discharge Detecting Function” to realize the air-discharge confirmation. “Lightest Discharge Gun in the market” to lighten the continual operation White LED Irradiator to facilitate the visualization of the discharging area. One-touch exchange of gun head and CR unit realized

Read more less

In Stock

$995.00

View options

Noiseken ESS-L1611 16 kV Electrostatic Discharge Simulator for IEC 61000-4-2 - ESDGuns.com

Visually Monitor and Target Electrostatic Discharge Points with LED Light on GT-30R Pistol

Noiseken ESD Simulators Noiseken ESS-L1611 16 kV Electrostatic Discharge Simulator for IEC 61000-4-2

In Stock

The Noiseken ESS-L1611 16 kV Electrostatic Discharge Simulator for IEC 61000-4-2 is a cost-oriented basic model ESD Simulator with a light weight discharge gun pistol attachable. The Noiseken GT-30R discharge gun has been renewed completely to materialize much more lightning and best gravity balance. Human load in the operation can be remarkably reduced comparing to the previous model. Electrostatic discharge can be confirmed with LED light on the body in this new discharge gun.

Read more less

In Stock

$0.00

View options

Noiseken ESD Simulators NoiseKen ESS-PS1 ESD Simulator

In Stock

NoiseKen ESS-PS1 ESD Simulator, comes equipped standard with a GT-31S pistol and the standard 150pF, 330 Ohm discharge module, now mounted at the pistol tip rather than inserted into a rear compartment like previous generation Noiseken ESD simulator systems. ESDGuns.com evaluated the new unit and has made it part of it's rental offering, despite the higher price point. NoiseKen ESS-PS1 ESD Simulator Features: Intuitive touchscreen menu on discharge gun Discharge module identification functionality Lightweight and intuitive NoiseKen Original Function “Pre-check Function” Equipped

Read more less

In Stock

$165.00

View options

Noiseken ESS-S3011 Advanced 30kV ESD Simulator System for Automotive, Commercial & Avionics Testing

Noiseken ESD Simulators Noiseken ESS-S3011 Advanced 30kV ESD Simulator System

In Stock

The Noiseken ESS-S3011 30kV ESD simulator system is the most advanced ESD immunity test solution on the market. Noiseken ESS-S3011 Features: “Pre-checking function” taking the confirmable test into the account “Discharge Detecting Function” to realize the air-discharge confirmation. “Lightest Discharge Gun in the market” to lighten the continual operation White LED Irradiator to facilitate the visualization of the discharging area. One-touch exchange of gun head and CR unit realized

Read more less

In Stock

$0.00

View options

P1202-2 set ESD Magnetic Field Coupling

Request Lead Time

The field source, which are included in the probe set ESD/magnetic field coupling, generates magnetic ESD fields. With this field, ICs are defined and reproducibly pulsed to determine their immunity against ESD fields. The reason for this is the ESD immunity of PC boards and electrical devices. The immunity is tested (IEC 61000-4-2). During the tests electric and magnetic fields are generated by coupled ESD interference into the PC boards. These fields affect the PC board surface and penetrate the IC casings. If fields penetrate the ICs, disturbance events will be generated. The IC interference via magnetic or electrical fields is a significant source of interference / interference path in addition to the conducted coupling of ESD interference above the ICs.The knowledge gained about IC EMC behaviour is streamlined into the development of an assembly. Hence, expensive redesigns are avoided and development costs are reduced.Furthermore, the use of the test methods for the determination of IC EMC parameters enables the IC producer to develop ICs more efficiently. The test set up needs the ICE1 test system and external devices.

Read more less

Request Lead Time

$0.00

View options

Reference Plane for Coaxial Current Target - ESD Calibration

ESDGuns.com PRP Portable Reference Plane for Coaxial Current Target

In Stock

Utilized with a current digital oscilloscope, the PRP provides adequate shielding to perform reliable and repeatble current waveform verifications on your ESD generator. 17" x 13" 4 Pounds Suitable for precompliance ESD generator calibration

Read more less

In Stock

$975.00

Standard rental package supplied with the Keytek Minizap MZ-15/EC ESD Gun

Thermo Keytek Rent Keytek Minizap MZ-15-EC 15kV ESD Simulator Gun

In Stock

The Thermo Scientific Keytek Minizap MZ-15/EC 16kV ESD simulator gun is a totally integrated lightweight hand-held tester featuring ease of use, and the ability to withstand long-term operation in rugged environments. By simply interchanging plug-in tips, you can test to risetime standards, as well as do ‘reality checks’ that indicate product performance in intended environments. Multiple ESD events can be generated by a human discharge, and also by other ESD simulators that introduce additional artificial and energetic multiple discharges. The MiniZap does not use a voltage multiplier, and won’t introduce testing errors and uncertainties due to streams of artificial, high-level ESD multiples. With its constant-voltage ESD simulator design feeding back and monitoring right from the tip, you know the EXACT voltage at which you’ve tested. The correct tip voltage is maintained to the instant of discharge; it then drops to prevent simulator-induced multiple The Keytek MiniZap MZ-15/EC test system is a self-contained ESD simulator gun that enables users to perform direct, indirect & diagnostic ESD testing via interchangeable plug-in tips. ESD is the most common cause of failure in computer-based equipment, and susceptibilities often occur during installation and networking. The diagnosis and remedy for ESD failures typically require test procedures developed in R&D, but implemented by QC, manufacturing, and field service. Practical and reliable, the KeyTek MiniZap MZ-15/EC ESD simulator gun and options are designed specifically for demanding applications such as these. It generates ESD simulation pulses that are real world, repeatable and correlatable – mandatory performance criteria for a company-wide ESD test program. Keytek Minizap MZ-15/EC Features: Intuitive operation Portable & self-contained Meets exact requirements of IEC 61000-4-2 Contact mode & air discharge ESD testing Generates real world, repeatable & correlatable ESD pulses E & H Field diagnostics Built-in safety features Field-configurable Rechargeable battery or AC powered

Read more less

In Stock

$295.00

View options

Schloder ESD Generators Rent Schloder SESD 230 30kV Handheld Battery Operated ESD Simulator

In Stock

The Schloder test generator SESD 216 simulates electrostatic discharge as defined in the standard IEC / EN 61000-4-2. It is the most ergonomical and lightweight of all handheld, battery operated 30kV ESD simulators on the market. It's compact design and lightweight chassis makes it easy for users to handle during long sessions of testing, evaluation or debugging. Schloder SESD 216 Rentals Includes: 30kV ESD Simulator Battery Charger (Also runs on AC during charge) Air Discharge Test Tip Contact Discharge Test Tip Ground Cable Carrying Case User Manual Calibration Certificate with Data and Waveforms 10% off Calibration Service for Life

Read more less

In Stock

$695.00 $276.25

View options
