RC Modules / Discharge Networks
Discharge Networks or RC Modules (Specific Resistance and Capacitance values) are required for general standards like IEC 61000-4-2, SAE J113 and industry specific standards like ISO 10605. Resistance is referred to in ohms (Ω), Capacitance is referred to in picofarad (pF or "puff"). The most commonly used Discharge Network is for IEC 61000-4-2 and ISO 10605, expressed as 330pF/330Ω. There are over 50 combinations of Resistance & Capacitance depending on the standards and the applicable electronics.
-
Teseq ESD Guns Teseq INA4553 330 pF-330 Ohm Discharge Module for NSG 438 Automotive ESD Simulator
The Teseq (Schaffner) INA4553 330 pF/330 Ohm discharge module is compatible only with the Teseq NSG 438 ESD Simulator Gun. Specifications: Capacitance: 330 pF Resistance: 330 Ohms Test Standards Met: ISO 10605 (2001), (2008)
$0.00
-
Haefely ESD Generators Haefely 4700622 RC Network 100pF-1500 Ohm for MIL-STD-883 - GR78-CORE
The Haefely 4700622 RC Network 100pF/1500 Ohm for MIL-STD-883 / GR78-CORE Human Body Model (HBM) is for use only with the Haefely ONYX 16 kV or Haefely ONYX 30 kV Specifications: Capacitance: 100 pF Resistance: 1500 Ohms Test Standards Met: MIL-STD-883 GR78-CORE
$99.00 - $499.00
-
Teseq ESD Guns Teseq INA 4561 Discharge Network 100 pF - 1500 Ohm per MIL-STD 883
The Teseq (Schaffner) INA 4561 Discharge Network 100 pF / 1500 Ohm per MIL-STD 883 for NSG 437/438 is compatible with the Teseq NSG 438 ESD Simulator Gun. Specifications: Capacitance: 100 pF Resistance: 1500 Ohm Used to test ESD per MIL-STD-883 Compatible with Teseq NSG 437 and NSG 438 Models
$295.00
-
Teseq ESD Guns Teseq INA4381 Automotive Discharge Network for ISO 10605 150pF-2kOhm
The Teseq INA 4381 automotive discharge network is compatible only with the Teseq NSG 437 or Teseq NSG 438 ESD Simulator Gun Specifications: Capacitance: 150 pF Resistance: 2 kΩ Test Standards Met: ISO 10605 (2001), (2008) SAEJ1113-13 GMW3091 GMW3094 GMW3097 GMW3100
$990.00 - $1,190.00
-
Haefely ESD Generators Haefely 4700621 RC Module 500 pF - 5000 Ohm for Mil-STD & Automotive ESD Testing
The Haefely 4700621 RC Module is for use with the Haefely ONYX 30 kV ESD Simulator Gun. Specifications: Capacitance: 500 pF Resistance: 5000 Ohms For use to 30 kV Test Standards Met: Meets automotive ESD standard ISO 14304 Meets military ESD standards Mil-STD-331B and STANAG 4239
$89.00 - $595.00
-
Teseq ESD Guns Rental - ISO 10605 Automotive RC Module Package for Teseq NSG 438
Automotive Package includes: INA 4381: 150 pF /2000 Ohms INA 4382: 330pF / 2000 Ohms INA 4553: 330 pF / 330 Ohms 150pF/330Ohm Standard Network Supplied with Every ESD Gun Calibrated with Teseq NSG 438 2 Days Free Transit - 30 Day Billing Cycle
$267.00 - $467.00
-
EMC Partner EMC Partner DM6 100pF - 1500ohm RC Module for IEC 61340-3-1 and Mil-STD-750D
The EMC Partner DM6 150pF / 330ohm RC module is required for use with the for EMC Partner ESD 3000 Pistol. The plug-in module meets human body model compliance standards IEC 61340-3-1, JEDEC 22-A114 and Mil-STD-750D. The discharge modules (DM) contain the high voltage source and the impulse network, making them optimized for the specific application and standard. The RC modules can be easily interchanged. EMC Partner ESD3000DM6 Features: Standards Met: IEC 61340-3-1 JEDEC 22-A114 Mil-STD-750D Capacitance/Resistance: 100pF / 1500ohm Voltage range (CD) Contact Discharge: +/- 0.2kV up to 8kV Voltage range (AD) Air Discharge: None
$395.00
-
Teseq ESD Guns Teseq INA 4559 Discharge Network 500 pF - 5 kOhm per Stanag 4239
The Teseq (Schaffner) INA 4559 Discharge Network 500 pF / 5 kOhm per Stanag 4239 is compatible with the Teseq NSG 438 ESD Simulator Gun. Specifications: Capacitance: 500 pF Resistance: 5 kOhm Compatible with Teseq NSG 437 and NSG 438 Models Test Standards Met: Stanag 4239
$0.00 - $90.00
-
Teseq ESD Guns Teseq INA4382 ISO 10605 Discharge RC Network for NSG 437-NSG 438 - 330pF-2kOhm
The Teseq INA 4382 automotive discharge network is compatible only with the Teseq NSG 438 ESD Simulator Gun. Specifications: Capacitance: 330 pF Resistance: 2 kΩ Test Standards Met: ISO 10605 (2001), (2008) SAEJ1113-13
$0.00
-
EMC Partner EMC Partner DM1 150pF - 330ohm Discharge Network for ESD 3000
The EMC Partner DM1 150pF / 330ohm Discharge Network for ESD 3000 meets IEC 61000-4-2 Ed.2: New test method and tolerances for impulse evaluation. The EMC Partner ESD3000 with DM1 fulfills BOTH Ed.1 and Ed.2 EMC Partner ESD3000DM1 Features: Capacitance/Resistance: 150pF / 330ohm Voltage range (CD) Contact Discharge: +/- 0.2kV up to 10kV Voltage range (AD) Air Discharge: +/- 0.2kV up to 16kV Compliance Standards: IEC 61000-4-2, ITU-T K20
$0.00
-
Teseq ESD Guns Teseq INA 4555 Discharge Network 500 pF - 500 Ohm per MIL-STD-464, Stanag 4239
The Teseq (Schaffner) INA 4555 Discharge Network 500 pF / 500 Ohm per MIL-STD-464, Stanag 4239 is compatible with the Teseq NSG 438 ESD Simulator Gun. Specifications: Capacitance: 500 pF Resistance: 500 Ohm Compatible with Teseq NSG 437 and NSG 438 Models Test Standards Met: MIL-STD-464 Stanag 4239
$0.00
-
Teseq ESD Guns Teseq INA4380 150pF-330Ω Discharge Network per IEC 61000-4-2
The Teseq INA 4380 automotive discharge network is compatible only with the Teseq NSG 438 ESD Simulator Gun. Specifications: Capacitance: 150pF Resistance: 330Ω Test Standards Met: IEC 61000-4-2 (2008) ISO 10605 (2001), (2008)
$1,175.00
-
Haefely ESD Generators Haefely 4700531 RC Module 150 pF - 2000 Ω for ISO 10605
The Haefely 4700531 RC Module is for use only with the Haefely ONYX 16 kV or Haefely ONYX 30 kV Specifications: Capacitance: 150 pF Resistance: 2 kΩ Test Standards Met: ISO 10605 (2001), (2008)
$89.00 - $595.00
-
EMC Partner EMC Partner DN1 150pF - 330ohm 30kV Discharge Network for ESD3000
The EMC Partner DN1 150pF / 330ohm Discharge Network for ESD 3000 meets IEC 61000-4-2 Ed.2: New test method and tolerances for impulse evaluation. The EMC Partner ESD3000 with DN1 fulfills BOTH Ed.1 and Ed.2 EMC Partner ESD3000DN1 Features: Capacitance/Resistance: 150pF / 330ohm Voltage range (CD) Contact Discharge: +/- 1kV up to 30kV Voltage range (AD) Air Discharge: +/- 1kV up to 30kV Compliance Standards: IEC 61000-4-2, RTCA/DO-160, PSA Peugeot-Citroën B21 7110, GMW 3100
$200.00
-
Haefely ESD Generators Haefely 4700619 RC Module 500 pF - 500 Ω for Military ESD Test Standards
The Haefely 4700619 RC Module is for use with the Haefely ONYX 30 kV Specifications: Capacitance: 500 pF Resistance: 500 Ohms For use to 30 kV Test Standards Met: Meet Mil-STD-331, Mil-DTL-23659D and STANAG 4239 ESD Test Standards
$89.00 - $595.00
-
EMC Partner EMC Partner RM32 Relay Module for ESD3000 Pistol
EMC Partner ESD3000RM32 Features: Relay Module required for all 30kV modules for EMC Partner ESD3000 Pistol Voltage range (CD) Contact Discharge: +/- 1kV up to 30kV Voltage range (AD) Air Discharge: +/- 1kV up to 30kV Compliance Standards: 0.7ns up to 1ns and < 400ps
$255.00 - $395.00
-
EMC Partner EMC Partner DM7 Discharge Module for IEC 61340-3-2 & JEDEC 22-A115 Machine Model (MM) ESD
The EMC Partner DM7 Discharge Module meets IEC 61340-3-2 & JEDEC 22-A115 Machine Model (MM) ESD immunity compliance standards. It requires use with the EMC Partner ESD 3000 electrostatic discharge generator. EMC Partner ESD3000DM7 Features: Capacitance/Resistance: 200pF / 0 ohm Voltage range (CD) Contact Discharge: +/- 0.08 kV up to 2.5 kV Voltage range (AD) Air Discharge: no AD Compliance Standards: IEC 61340-3-2 & JEDEC 22-A115 Machine Model (MM) ESD
$217.00 - $295.00
-
Haefely ESD Generators Haefely 4700532 RC Module 330 pF - 2000 Ω for ISO 10605
The Haefely 4700532 RC Module is for use only with the Haefely ONYX 16 kV or Haefely ONYX 30 kV Specifications: Capacitance: 330 pF Resistance: 2 kΩ Test Standards Met: ISO 10605 (2001), (2008)
$89.00 - $595.00
-
Teseq ESD Guns Teseq INA 4591 Discharge Network 250 pF - 500 Ohm
The Teseq (Schaffner) INA 4591 Discharge Network 250 pF / 500 Ohm for NSG 437/438 is compatible with the Teseq NSG 438 ESD Simulator Gun. Specifications: Capacitance: 250 pF Resistance: 500 Ohm Compatible with Teseq NSG 437 and NSG 438 Models
$0.00 - $90.00
-
EMC Partner EMC Partner ESD3000DN4 500 pF - 5000 Ohm Network for Testing Explosive Devices to MIL-STD-331
EMC Partner ESD3000DN4 500 pF / 5000 Ohm Network is used to meet MIL-STD-331 and other electrostatic immunity standards for testing explosive devices. EMC Partner ESD3000DN4 Features: Capacitance/Resistance: 500pF / 5000ohm Voltage range (CD) Contact Discharge: +/- 1kV up to 30kV Voltage range (AD) Air Discharge: +/- 1kV up to 30kV Compliance Standards: MIL-STD-331, STANAG 4239, ISO 14304, MIL-STD-1512 EMC Partner ESD3000DN4 Package Includes: DN4 500pF/5000Ohm RC module Air Discharge Tip Contact Tip Air Discharge Electrode Diamete 30mm Permanent Magnet CD Manual Calibration Report *The ESD3000DN4 is a 30kV module required the ESD3000RM32 relay module and ESD3000 discharge pistol to complete testing.
$395.00
-
Teseq ESD Guns Teseq INA4383 Discharge Network 150pF-330Ohm per ANSI C63.16 Hand - Metal Model ESD Compliance
The Teseq (Schaffner) INA4383 Discharge Network 150pF/330Ohm per ANSI C63.16 Hand / Metal Model ESD Compliance is compatible with the Teseq NSG 438 ESD Simulator Gun. Specifications: Capacitance: 150 pF Resistance: 330 Ohm Compatible with Teseq NSG 437 and NSG 438 Models Test Standards Met: ANSI C63.16 Hand / Metal Model
$295.00 - $1,195.00
-
EMC Partner EMC Partner ESD3000DM5 RC Module Set for RTCA-DO-160 & EUROCAE ED-14D
The EMC Partner ESD3000DM5 150pF / 330ohm RC module is required for use with the for EMC Partner ESD 3000 Pistol. The plug-in module meets requirements per RTCA/DO-160 and EURO CAE ED-14D The discharge modules (DM) contain the high voltage source and the impulse network, making them optimized for the specific application and standard. The RC modules can be easily interchanged. EMC Partner ESD3000DM6 Features: Standards Met: RTCA/DO-160 EUROCAE ED-14D Capacitance/Resistance: 150pF / 330ohm Voltage range (CD) Contact Discharge: None Voltage range (AD) Air Discharge: +/- 1kV up to 30kV
$39.00 - $299.00
-
EMC Partner EMC Partner ESD3000DN32-IND1 150 pF - 150 Ohm RC Module
EMC Partner ESD3000DN32-IND1 150 pF / 150 Ohm RC Module EMC Partner ESD3000DN32-IND1 Features: Meets ABD0100.1.2, IEC 801-2 Capacitance/Resistance: 150pF / 150ohm ±10% Voltage range (CD) Contact Discharge: 2 - 30kV Requires ESD3000RM32 High Voltage Relay and ESD3000 ESD Gun EMC Partner ESD3000DN32-IND1 Package Includes: ESD3000DN32-IND1 RC module Air Discharge Tip Contact Tip Air Discharge Electrode Diameter 30mm Permanent Magnet CD Manual Calibration Report *The ESD3000DN32-IND1 is a 30kV module required the ESD3000RM32 relay module and ESD3000 discharge pistol to complete testing.
$2,250.00
-
Noiseken ESD Simulators Noiseken Discharge Resistors and Capacitor Units for TC-815 ESD Guns
The EMC Shop has an assortment of Noiseken Resistance/Capacitance combinations available as a lot. Inquire for pricing.
$0.00
-
EMC Partner EMC Partner ESD3000DN32-MIL2 450 pF - 150 Ohm Network for Military ESD Testing
EMC Partner ESD3000DN32-MIL2 450 pF / 150 Ohm Network for Military ESD Testing EMC Partner ESD3000DN32-MIL2 Features: Capacitance/Resistance: 450pF / 150ohm ±10% Voltage range (CD) Contact Discharge: 2 - 30kV Requires ESD3000RM32 High Voltage Relay and ESD3000 ESD Gun EMC Partner ESD3000DN32-MIL2 Package Includes: ESD3000DN32-MIL2 RC module Air Discharge Tip Contact Tip Air Discharge Electrode Diameter 30mm Permanent Magnet CD Manual Calibration Report *The ESD3000DN5 is a 30kV module required the ESD3000RM32 relay module and ESD3000 discharge pistol to complete testing.
$595.00 - $3,975.00
-
EMC Partner EMC Partner ESD3000DN32-MIL3 500 pF - 0 Ohm Network for MIL-STD-1576
EMC Partner ESD3000DN32-MIL3 500 pF / 0 Ohm Network is used to meet MIL-STD-1576. EMC Partner ESD3000DN32-MIL3 Features: Capacitance/Resistance: 500pF / 0 ohm ±10% Voltage range (CD) Contact Discharge: 2 - 30kV Compliance Standards: MIL-STD-1576 Requires ESD3000RM32 High Voltage Relay and ESD3000 ESD Gun EMC Partner ESD3000DN32-MIL3 Package Includes: ESD3000DN32-MIL3 500pF/0Ohm RC module Air Discharge Tip Contact Tip Air Discharge Electrode Diameter 30mm Permanent Magnet CD Manual Calibration Report *The ESD3000DN5 is a 30kV module required the ESD3000RM32 relay module and ESD3000 discharge pistol to complete testing.
$595.00 - $3,975.00
-
Haefely ESD Generators Rental - ISO 10605 Automotive RC Module Package for Haefely ONYX 16 & 30
The Haefely ISO 10605 Automotive RC Module Package is for use only with the: Haefely ONYX 16 kV or Haefely ONYX 30 kV Specifications: Capacitance: 150 pF, 330 pF Resistance: 330Ω, 2 kΩ Test Standards Met: ISO 10605 (2001), (2008)
$267.00
-
Haefely ESD Generators Haefely 4700618 RC Module 330 pF - 330 Ω for ISO 10605
The Haefely 4700618 RC Module is for use only with the Haefely ONYX 16 kV or Haefely ONYX 30 kV Specifications: Capacitance: 330 pF Resistance: 330Ω Test Standards Met: ISO 10605 (2001), (2008)
$89.00 - $595.00
-
Noiseken ESD Simulators Noiseken 100pF-1.5k Ohm CR network for GT-30R - 06-00079B
Noiseken 100pF-1.5k Ohm CR network for GT-30R / 06-00079B
$895.00
-
EMC Partner EMC Partner ESD3000DN5 500 pF - 500 Ohm Network for MIL-STD-331
EMC Partner ESD3000DN5 500 pF / 5000 Ohm Network is used to meet MIL-STD-331 and other electrostatic immunity standards. EMC Partner ESD3000DN5 Features: Capacitance/Resistance: 500pF / 500ohm Voltage range (CD) Contact Discharge: +/- 1kV up to 30kV Voltage range (AD) Air Discharge: +/- 1kV up to 30kV Compliance Standards: MIL-STD-331, STANAG 4239, MIL-SRL-23659D EMC Partner ESD3000DN5 Package Includes: DN5 500pF/5000Ohm RC module Air Discharge Tip Contact Tip Air Discharge Electrode Diamete 30mm Permanent Magnet CD Manual Calibration Report *The ESD3000DN5 is a 30kV module required the ESD3000RM32 relay module and ESD3000 discharge pistol to complete testing.
$395.00
-
Teseq ESD Guns Teseq INA4569 200 pF-0 Ohm R-C Module for Machine Model (MM) Electrostatic Discharge Testing
The Teseq (Schaffner) INA4569 Discharge Network 200pF/0Ohm per JEDEC 22-A115, IEC 61340-3-2 and other standards for Machine Model ESD compliance is compatible with the Teseq NSG 437 and NSG 438 Models Capacitance: 200 pF Resistance: 0 Ohm Test Standards Met: Compatible with Teseq NSG 437 and NSG 438 ModelsCompatible with Teseq NSG 437 and NSG 438 Models ANSI C63.16 Hand / Metal Model JEDEC 22-A115 IEC 61340-3-2
$89.00
-
EMC Partner EMC Partner DN3 Automotive Discharge Module for ISO 10605 ESD Compliance
The EMC Partner DN7 Automotive Discharge Module meets ISO TR10605, SAE JSSI-IS, FORD AB/AC automotive ESD immunity compliance standards. It requires use with the EMC Partner ESD 3000 electrostatic discharge generator and EMC Partner RM32 Relay Module. EMC Partner ESD3000DN3 Features: Capacitance/Resistance: 150pF / 2000 ohm Voltage range (CD) Contact Discharge: 30 kV Voltage range (AD) Air Discharge: 30 kV Compliance Standards: Automotive ISO TR10605, SAE JSSI-IS, FORD AB/AC
$171.00 - $249.00
-
Teseq ESD Guns Teseq INA4550 1000pF-2000Ω Discharge Network per ES-X 44017 HMC
The Teseq INA 4550 automotive discharge network is compatible only with the Teseq NSG 438 ESD Simulator Gun. Specifications: Capacitance: 150pF Resistance: 330Ω Test Standards Met: ES-X 44017 HMC (Hyundai Motor Company) Manufacturer: Teseq ESD Guns
$990.00
-
Teseq ESD Guns Teseq (Schaffner) INA 435 (403-077B) Standard Discharge (RC) Network for NSG 435 ESD Gun
Teseq INA 435 (403-077B) is the standard discharge (RC) network used with the NSG 435 ESD Gun. Capacitance: 150pF Resistance: 330Ω For use with Teseq (Schaffner) NSG 435 ESD Simulator Gun
$0.00
