Rent, buy or lease 3ctest ESD guns and associated R/C networks to simulate the different types of current waveforms defined in compliance standards. ESDguns.com offers accredited calibrations and same day, overnight shipping on new, used and rental units.
The 3ctest EDS20H is a state of the art electrostatic discharge (ESD) simulator for immunity and compliance testing from 1 kV to 18 kV. It is a self contained pistol housing the High voltage source, battery and RC networks in one lightweight assembly. The user friendly touchscreen, ergonomic design, modular R/C units, remote control software, built-in LED light and temperature and humidity display allows quick and trouble-free us in all types of test sites.3ctest EDS20H Includes: 20kV ESD Generator AC Power Adapter for continuous testing QTY 2 Batteries Battery Charger Air Discharge Tip Contact Discharge Tip 150pF/330 Ohm R/C Network Grounding Cable HV Alligator Clip Ruggedized Carrying Case with Shoulder Strap Traceable Calibration Certificate User Manual 10% off Calibration Service for Life 3ctest EDS20H Features: Air- and Contact- Discharge: 1000-20,000V±5% Rise time: 0.6-1ns RC module: 150pF/330Ω Automatic identification of discharge module Voltage hold time: >5s As per: IEC61000-4-2, GB/T17626.2 LCD Touchscreen Automatic Polarity Switching Temperature & Humidity Monitoring Battery or mains operation with long battery life
$357.00 - $1,606.50
The EDS MAX is 3CTEST’s fourth generation ESD simulator in compliance with IEC 61000-4-2:2025 and other standards. This new product has a high - definition color touch screen, along with compact mechanical design, intuitive UI, lightweight, and impeccable waveforms. With three test modes, the EDS MAX offers customers convenient operation tailored to their testing needs and requirements, ideal from the research and development stage allthe way through to the verification and certification for ESD immunity. Test Standards: EN/IEC 61000-4-2 MIL-STD-461 CS118 DO-160 Section 25 Bellcore GR-1089-Core ISO 14304 IEC 61000-6-2 IEC 61000-6-1 IEC 61326 IEC 61340-3-1 ITU-T K.20 Models: EDS MAX16 - max discharge voltage to 17kV EDS MAX20 - max discharge voltage to 20kV All include the 150pF/330Ohm R/C module required in the above standards. Additionaly modules available. Air and contact discharge tips: Test Voltage 0.5 kV ~ 20 kV( ± 5% ) Voltage Step 100 V Polarity +, -, + / - Holding Time 5 s ~ 10 s Discharge Tip Air discharge tip and Contact discharge tip RC module 150 pF / 330 ohm RC Module Identification Automatic Identification and display Control Mode Touch screen, trigger button, optical fiber remote control Frequency Single, 0.1 Hz,0.2 Hz,0.5 Hz,1 Hz,2 Hz ,5 Hz,10 Hz and 20 Hz Trigger Mode Automatic, manual, remote Counter 1 ~ 9999 Sequence Test Up to 4 sequence levels Counter Countering happens upon tips voltage lowered than setting voltage thresholds Voltage Thresholds 50%, 60%, 70%, 80%, 90% Temperature and Humidity Built-in temperature and humidity meter, serving as real-time test environment record and protection function. Battery Type Lithium battery Battery Group Voltage 3 * 3.7 V Battery Capacity 27 Wh Battery Life 12h @ contact discharge 20 kV, 1 Hz, first positive and then negative 18h@ contact discharge 8 kV, 1Hz, first positive and then negative Power Supply for Battery Charger 100 V ~ 240 V，50 ~ 60 Hz Battery Charge Time Approx. 5 h Service Life 300 times ＞ 80% Display Screen 3.5 inches color screen Language English, Chinese Auto Power OFF Function Power off automatically upon no operations: 5 min / 10 min / 15 min / 30 min / never Screen Brightness 0 ~ 100% Lock Screen Lock screen upon no operation: 5 min / 10 min / 15 min / 30 min / never Memory latest 4 groups testing parameters Communication mode Optical fiber Grounded Port 4mm banana plug Dimension 285 mm × 85 mm × 245 mm Weight Approx.1.25kg(Incl. battery) Ambient Temperature 5 ℃ ~ 40℃ Relative Humidity 20% ~ 80% (no condensation) Atmospheric Pressure 86 kPa ~ 106 kPa Standard Accessory Kit: Air Tip Contact Tip RC Module AC Adapter Ground Cable Alligator Clip Battery x2 Carrying Case Manual Stand Additional Accessories: EDS MAX-REMOTE (for PC interface) Corelab Software EDS MAX-DCPower - AC 110/220V input, can replace battery pack
$260.00 - $475.00
The 3ctest EDS 30T Electrostatic Discharge ESD Generator is a state of the art electrostatic discharge (ESD) simulator for immunity and compliance testing from 1 kV to 30 kV. The unit has the best price point of its 30 kV simulator comparables and is growing in popularity among engineering firms and manufacturers performing debugging and precompliance test evaluations.
$990.00 - $13,950.00
The static electricity between human body and an object or between two objects sometimes can be up to tens of thousands of volts, which may cause electrical and electronic equipments circuit malfunction or even damage. EDS 30V is a most advanced intelligent electrostatic discharge generator, the output voltage 30kV, it is also China’s first independent research and development product with collection discharge tip and touch screen control in an electrostatic discharge simulator, in accordance with ISO 10605 and GB/T 19951 standards. LCD touch screen is simple and easy to operate, RC module can be replaced, the built-in temperature hygrometer, remote control software, to ensure the reliability of all kinds of tests. Applications: Communication Information technology Telecom Automotive Military Medical Aviation Broadcast and TV New energy and power Railway 3ctest EDS 30V Features: Air- and Contact- Discharge: 1000-30,000 Volts ±5% Resolution: 100 Volts Hold Time: >5 seconds Frequency Repetition: Single/0.2/0.2/0.5/1/2/5/10/20 Hz Standards Met: Bellcore GR-1089-Core, IEC/EN 61325, IEC/EN 61000-6-1 and 6-2, ISO 10605, ITU-TK.20, GB/T 17626.2 and more... Integrated sensor to monitor temperature and humidity Rise Time: 0.8 ns ±25% (0.6 to 1 ns) Current Peak Value Accuracy: ±10%
$1,195.00 - $14,195.00
The EDS MAX30 is a state-of-the-art intelligent electrostatic discharge generator with an output voltage of 30 kV. It is an electrostatic discharge simulator that integrates discharge gun head and touch screen control, and operates in accordance with ISO 10605 and GB/T 19951 standards. Users can choose AC or built-in battery, the RC module can be easily interchanged, and the built-in temperature and humidity meter ensures reliability in various testing scenarios. Test Standards: EN/IEC 61000-4-2 ISO 10605 MIL-STD-331 MIL-STD-461 CS118 DO-160 Section 25 ompliant With Standards GB/T 19951:2019、ISO 10605:2023IEC 61000-4-2:2025、GB/T 17626.2:2018 Voltage Range 0.2 kV ~ 30 kV(± 5%) Voltage Resolution 100 V step Polarity Positive/Negative/ alternate Maintain Time 5 s ~10 s Discharge Electrode Air discharge round head/contact discharge pointed head RC Module 150 pF/330 ohm RC Module Recognition Automatically recognize and display numerical values Control Mode Touch screen, trigger button, fiber optic remote control Repetition Frequency Single, 0.1 Hz, 0.2 Hz, 0.5 Hz, 1 Hz, 2 Hz, 5 Hz, 10 Hz, and 20 Hz Trigger Method Automatic and manual Pulse Counter 1 ~ 9999 Scheduling Test Up to 4 scheduling levels, tested in sequence TDC Counting Function Count once when the voltage of the gun head is below the set voltage threshold Self Inspection Before use, the self check function can be used to automatically verify Temperature and Humidity Built in temperature and humidity meter, can be used for environmental recording and instrument protection Battery Pack Parameters( Optional Accessories Battery Pack TST231–3S1P) Battery Type Lithium battery Module Voltage 11.1 V Capacity 27 Wh Battery Life Contact discharge 8 kV, 1 Hz, alternate , about 6 hoursContact discharge 30 kV, 1 Hz, alternate, about 4 hours Battery Charging Time About 4 hours, fully charged automatic protection Cycle Life Charging and discharging times 300 times>80% battery capacity Display 3.5-inch color screen Scope of Working Power Supply 100 V ~ 240 V(±10%) 50/60 Hz Language Chinese and English Brightness Setting 0 ~ 100% brightness setting Screen off Setting Automatically turn off screen without operation: 5 min/10 min/15 min/30 min/never Record Logs Record the last 4 sets of experimental parameters Communication Method Fiber optic communication Instrument Grounding Connection Method 4 mm banana socket Host Size 207 mm（W）*160 mm（H）*310 mm（D） Instrument Weight About 7.35 kg (including guns) Ambient Temperature 5℃ ~ 40℃ Relative Humidity 20% ~ 80% ,RH(no condensation) Atmospheric Pressure 86 kPa ~ 106 kPa Standard Accessory Kit: Air Tip Contact Tip RC Module AC Adapter Ground Cable Alligator Clip Battery x2 Carrying Case Manual Stand
$0.00 - $8,975.00
In general, a wearable device should be tested according to the requirements for table top equipment. For additional experimental ESD testing on wearable devices, the recommended energy storage capacitor and discharge resistor are 200 pF and 50 Ω, respectively, to reproduce the most severe discharge current condition from a wearable device on the waist. Fundamentally, the phenomenon of ESD experienced by wearable devices attached to a charged human body are similar to a charged device model attached to the human body. The wearable device is charged with a test voltage applied from a 200 pF storage capacitor and a 50 Ω discharge resistor in series, which is connected to the RGP using a high-voltage relay.
$0.00
The 3ctest EDS 10IC is specially designed for HBM and MM ESD immunity test requirements, applicable to semiconductor devices like LED, transistors, IC, etc, as per IEC, ESDA, JEDEC, MIL, etc. At the same time, fully comply with the severest ESD voltage levels in the standards above. Rent, buy or lease the 3ctest EDS 10IC HBM and MM ESD Immunity Tester. Test Standards Met: ANSI/ESDA/JEDEC JS-001-2024 MIL-STD-883-3 (Formerly MIL-STD-883, Method 3015) ANSI/ESDA/JEDEC JESD22-A115C ESD SP5.2-2019
$0.00 - $1,795.00
