The static electricity between human body and an object or between two objects sometimes can be up to tens of thousands of volts, which may cause electrical and electronic equipments circuit malfunction or even damage. EDS 30V is a most advanced intelligent electrostatic discharge generator, the output voltage 30kV, it is also China’s first independent research and development product with collection discharge tip and touch screen control in an electrostatic discharge simulator, in accordance with ISO 10605 and GB/T 19951 standards. LCD touch screen is simple and easy to operate, RC module can be replaced, the built-in temperature hygrometer, remote control software, to ensure the reliability of all kinds of tests.
Applications:
Communication
Information technology
Telecom
Automotive
Military
Medical
Aviation
Broadcast and TV
New energy and power
Railway
3ctest EDS 30V Features:
Air- and Contact- Discharge: 1000-30,000 Volts ±5%
Resolution: 100 Volts
Hold Time: >5 seconds
Frequency Repetition: Single/0.2/0.2/0.5/1/2/5/10/20 Hz
Standards Met: Bellcore GR-1089-Core, IEC/EN 61325, IEC/EN 61000-6-1 and 6-2, ISO 10605, ITU-TK.20, GB/T 17626.2 and more...
Integrated sensor to monitor temperature and humidity
Rise Time: 0.8 ns ±25% (0.6 to 1 ns)
Current Peak Value Accuracy: ±10%
