The EDS MAX is 3CTEST’s fourth generation ESD simulator in compliance with IEC 61000-4-2:2025 and other standards. This new product has a high - definition color touch screen, along with compact mechanical design, intuitive UI, lightweight, and impeccable waveforms.
With three test modes, the EDS MAX offers customers convenient operation tailored to their testing needs and requirements, ideal from the research and development stage allthe way through to the verification and certification for ESD immunity.
Test Standards:
EN/IEC 61000-4-2
MIL-STD-461 CS118
DO-160 Section 25
Bellcore GR-1089-Core
ISO 14304
IEC 61000-6-2
IEC 61000-6-1
IEC 61326
IEC 61340-3-1
ITU-T K.20
Models:
EDS MAX16 - max discharge voltage to 17kV
EDS MAX20 - max discharge voltage to 20kV
All include the 150pF/330Ohm R/C module required in the above standards. Additionaly modules available.
Air and contact discharge tips:
Test Voltage
0.5 kV ~ 20 kV( ± 5% )
Voltage Step
100 V
Polarity
+, -, + / -
Holding Time
5 s ~ 10 s
Discharge Tip
Air discharge tip and Contact discharge tip
RC module
150 pF / 330 ohm
RC Module Identification
Automatic Identification and display
Control Mode
Touch screen, trigger button, optical fiber remote control
Frequency
Single, 0.1 Hz,0.2 Hz,0.5 Hz,1 Hz,2 Hz ,5 Hz,10 Hz and 20 Hz
Trigger Mode
Automatic, manual, remote
Counter
1 ~ 9999
Sequence Test
Up to 4 sequence levels
Counter
Countering happens upon tips voltage lowered than setting voltage thresholds
Voltage Thresholds
50%, 60%, 70%, 80%, 90%
Temperature and Humidity
Built-in temperature and humidity meter, serving as
real-time test environment record and protection function.
Battery Type
Lithium battery
Battery Group Voltage
3 * 3.7 V
Battery Capacity
27 Wh
Battery Life
12h @ contact discharge 20 kV, 1 Hz, first positive and then negative
18h@ contact discharge 8 kV, 1Hz, first positive and then negative
Power Supply for Battery Charger
100 V ~ 240 V，50 ~ 60 Hz
Battery Charge Time
Approx. 5 h
Service Life
300 times ＞ 80%
Display Screen
3.5 inches color screen
Language
English, Chinese
Auto Power OFF Function
Power off automatically upon no operations: 5 min / 10 min / 15 min / 30 min / never
Screen Brightness
0 ~ 100%
Lock Screen
Lock screen upon no operation:
5 min / 10 min / 15 min / 30 min / never
Memory
latest 4 groups testing parameters
Communication mode
Optical fiber
Grounded Port
4mm banana plug
Dimension
285 mm × 85 mm × 245 mm
Weight
Approx.1.25kg(Incl. battery)
Ambient Temperature
5 ℃ ~ 40℃
Relative Humidity
20% ~ 80% (no condensation)
Atmospheric Pressure
86 kPa ~ 106 kPa
Standard Accessory Kit:
Air Tip
Contact Tip
RC Module
AC Adapter
Ground Cable
Alligator Clip
Battery x2
Carrying Case
Manual
Stand
Additional Accessories:
EDS MAX-REMOTE (for PC interface)
Corelab Software
EDS MAX-DCPower - AC 110/220V input, can replace battery pack
