EMC Partner DM7 Discharge Module for IEC 61340-3-2 & JEDEC 22-A115 Machine Model (MM) ESD

Description

The EMC Partner DM7 Discharge Module meets IEC 61340-3-2 & JEDEC 22-A115 Machine Model (MM) ESD immunity compliance standards. It requires use with the EMC Partner ESD 3000 electrostatic discharge generator.

EMC Partner ESD3000DM7 Features:

  • Capacitance/Resistance: 200pF / 0 ohm
  • Voltage range (CD) Contact Discharge: +/- 0.08 kV up to 2.5 kV
  • Voltage range (AD) Air Discharge: no AD
  • Compliance Standards: IEC 61340-3-2 & JEDEC 22-A115 Machine Model (MM) ESD

    Read more

    EMC Partner DM7 Discharge Module for IEC 61340-3-2 & JEDEC 22-A115 Machine Model (MM) ESD

    Product form

    In Stock  In Stock
    Monday to friday we offer next day delivery if the product is in stock and exceptions on holidays.

    Request Lead Time
    Equipment comes and goes everyday, we aren't automated for this website, contact us for status.

    International
    Depending on where you’re located, we offer next day delivery. Check your status on this link

    $295.00
