Thermo Keytek

The Thermo Scientific Keytek Minizap MZ-15/EC 16kV ESD simulator gun is a totally integrated lightweight hand-held tester featuring ease of use, and the ability to withstand long-term operation in rugged environments. By simply interchanging plug-in tips, you can test to risetime standards, as well as do ‘reality checks’ that indicate product performance in intended environments. Multiple ESD events can be generated by a human discharge, and also by other ESD simulators that introduce additional artificial and energetic multiple discharges. The MiniZap does not use a voltage multiplier, and won’t introduce testing errors and uncertainties due to streams of artificial, high-level ESD multiples. With its constant-voltage ESD simulator design feeding back and monitoring right from the tip, you know the EXACT voltage at which you’ve tested. The correct tip voltage is maintained to the instant of discharge; it then drops to prevent simulator-induced multiple The Keytek MiniZap MZ-15/EC test system is a self-contained ESD simulator gun that enables users to perform direct, indirect & diagnostic ESD testing via interchangeable plug-in tips.  ESD is the most common cause of failure in computer-based equipment, and susceptibilities often occur during installation and networking. The diagnosis and remedy for ESD failures typically require test procedures developed in R&D, but implemented by QC, manufacturing, and field service. Practical and reliable, the KeyTek MiniZap MZ-15/EC ESD simulator gun and options are designed specifically for demanding applications such as these. It generates ESD simulation pulses that are real world, repeatable and correlatable – mandatory performance criteria for a company-wide ESD test program. Keytek Minizap MZ-15/EC Features: Intuitive operation Portable & self-contained Meets exact requirements of IEC 61000-4-2 Contact mode & air discharge ESD testing Generates real world, repeatable & correlatable ESD pulses E & H Field diagnostics Built-in safety features Field-configurable Rechargeable battery or AC powered

Read more less

Replacement AC power adapters for Keytek Minizap ESD Simulators MZ-15 and MZ-15/EC models

Read more less

For descriptions, videos and more visit the Rent Thermo Keytek Minizap MZ-15/EC web page. Right now, ESDguns.com has an excess inventory of rental units and has allocated this unit for sale. Used Keytek Minizap MZ-15/EC Features: Recently rebuilt internal battery Fresh NIST Calibration Certificate Industry best 100 Day warranty Ships Immediately Rent Keytek Minizap ESD Simulators here. TPC-2A and TPA-2 Included Standard - additional tip and accessories available Thermo Keytek Minizap Video Overview

Read more less

The KeyTek Series 2000 hand-held or tripod-mounted ESD simulation test system provides a combination of performance characteristics that enable users to test to various ESD standards including IEC, ANSI, SAE and MIL-STD. Interchangeable discharge networks, current injection adapters, and tips (bundled or stand-alone) all plug directly into the discharger’s barrel, and facilitate testing to a broad range of ESD test methodologies to help users achieve market and company-driven quality objectives, and regulatory standards. The basic system is comprised of two interconnected units: the ESD-1 Discharger (or gun) that may be either hand-held or tripod mounted, and its associated Power Supply/Control Unit PSC-1. The ESD-1 Discharger contains a basic handle, polarity switch, high voltage set knob, a Digital Stored Voltage Monitor (DVM), and an audible discharge monitor that informs user when a discharge has occurred. The Power Supply/Control Unit includes selectors for repetition rates, charge rate and burst/normal modes. Keytek Series 2000 Features: Continuously selectable voltage from 0 to 25kV, positive and negative Interchangeable discharge networks, current injection adapters & tips for ESD testing to multiple standards Contact mode and air discharge testing including auxiliary adapters for air discharge generation & all five of its basic components Single-shot or programmable repetitive operating modes Hand-held or tripod-mounted Available Networks for Keytek Series 2000: DN-10 Discharge Network: IEC 61000-4-2 human-body-model Discharge Network (150 pF/330 Ω). DN-1 Discharge Network: IEC human-body-model Discharge Network (150 pF/150 Ω). ** DN-2 Discharge Network: NEMA Part DC33 and MIL STD 883E Discharge Network (100 pF/1500 Ω) DN-3 Discharge Network: Upper/lower-body-model Discharge Network (700 pF/100K/150 pF/150 Ω) DN-4 Discharge Network: Segmented-body-model Discharge Network (700 pF/100K/150 pF/150 Ω/20 pF-50 Ω) DN-6 Discharge Network: Optimum basic human-body-model network: EIA Std, PN-1361 (Draft 6, 1985) Discharge Network (100 pF/500 Ω) ** DN-10 may be substituted directly for DN-1; IEC Contact Mode module, CIA-V (for use with DN-10) may be directly substituted for DN-6 and HT-10/DT-4.

Read more less

The Keytek TPC-2A contact discharge tip is the most recent generation tip used with the Keytek Minizap MZ-15 and MZ-15/EC ESD simulators, compliant to IEC 61000-4-2, edition 2 and 3. ESDguns.com stocks replacement tips for easy ordering and replacement.

Read more less

The test voltage levels of the MZ-30 are more than sufficient for compliance to required IEC standard level 4 (15 kV) levels. Essentially a design tool, it allows you to identify the conditions where your product begins to degrade or malfunction (limit value), prior to production, and thus is also ideal for testing to category- or companydriven quality standards. The operation panel has keys and a rotary knob, which allow you to directly set test levels specified by the IEC standard. These controls facilitate adjustment for standardcompliance tests and other various settings.  In addition to the standard 150 pF capacitor unit and 330O discharge resistor, a variety of optional components are available including a 330 pF capacitor unit and 2kO discharge resistor. The MZ-30 also supports the seven discharge current waveforms prescribed for the waveform calibration method laid down in a target compliant with IEC61000-4-2 Editions 1. In addition, it was designed to suppress waveform ringing to improve waveform quality. The MZ-30 also supports the seven discharge current waveforms prescribed for the waveform calibration method laid down in a target compliant with IEC61000-4-2 Editions 1. In addition, it was designed to suppress waveform ringing to improve waveform quality. Keytek Minizap MZ-30 Features: Intuitive operation Portable & self-contained Meets exact requirements of IEC 61000-4-2 Contact mode & air discharge ESD testing Generates real world, repeatable & correlatable ESD pulses E & H Field diagnostics Built-in safety features Field-configurable AC powered

Read more less

The Keytek ZapMaster is a automated, high-speed ESD test system developed to test ICs and advanced electronic devices. The ZapMaster system can be configured from 64 pin (Model 7/1) to a 256 pin (Model 7/4) system in 64 pin increments. The ZapMaster delivers clean repeatable waveforms to any pin or combination of pins via a fully automated switching matrix and will test up to 8 devices simultaneously. The ZapMaster will supply precise ESD stimuli to selected pin devices and perform failure analysis via a rapid curve trace and optional Vcc/Icc measurements before and after each zap or series of zaps. As zap levels are increased for each series of zaps, failures are detected through a number of user defined failure criteria. The resulting data is displayed, analyzed and stored. The ZapMaster performs ESD, latch-up and socketed CDM testing to a variety of standards and range of voltages. Meets Human Body Model (HBM) Compliance Standards: MIL-STD-883D; 50V to 8kV MIL-STD-883D; 10V to 2.2kV MIL-STD-883D; 25V to 6kV MIL-STD-883D; 50V to 12.5kV ESD Association 5.1; 50V to 8kV IEC 61000-4-2; 50V to 8kV JESD22-A114 Meets Machine Model (MM) Compliance Standards: JESD22-A115; 25V - 2kV ESD Association 5.2; 25V - 2kV AEC Standard; 50V - 1.5kV EIA/J Standard; 25V - 2kV Socketed Charged Device Model (CDM) Latch-up JEDEC 17 EIA/J ESD Induced 200pF/0W , 5V to 800V EIA/J ESD Induced 500pF/0W , 5V to 800V

Read more less

Keytek (Thermo Fisher) RCDM3 Description: The KeyTek RCDM3 is a robotic style Charged Device Model (CDM) test system enabling the identification of CDM ESD threats to new devices prior to design release, or for postproduction failure analysis simulation. A turnkey PC-controlled system, RCDM3 features three independent video cameras and a built in vacuum ‘device retention’ system for rapid set-up. Devices of virtually any size or configuration can be stressed. The system provides efficient testing regimens and easily retrievable test data. Available with ESDA STM 5.3.1, JEDEC JESD22-C101 standards, or both. Test standards ESDA STM 5.3.1 or JEDEC, JESD22-C101 standards, or both 3 independent video cameras allow fast precision device alignment Built-in vacuum device hold-down system Accommodates testing of virtually any size device package Zap detection circuit for confirmed discharge event Safety interlocks guard operator safety

Read more less
