Keytek Series 2000 ESD Simulation Test System to 25kV

Description

The KeyTek Series 2000 hand-held or tripod-mounted ESD simulation test system provides a combination of performance characteristics that enable users to test to various ESD standards including IEC, ANSI, SAE and MIL-STD. Interchangeable discharge networks, current injection adapters, and tips (bundled or stand-alone) all plug directly into the discharger’s barrel, and facilitate testing to a broad range of ESD test methodologies to help users achieve market and company-driven quality objectives, and regulatory standards.

The basic system is comprised of two interconnected units: the ESD-1 Discharger (or gun) that may be either hand-held or tripod mounted, and its associated Power Supply/Control Unit PSC-1. The ESD-1 Discharger contains a basic handle, polarity switch, high voltage set knob, a Digital Stored Voltage Monitor (DVM), and an audible discharge monitor that informs user when a discharge has occurred. The Power Supply/Control Unit includes selectors for repetition rates, charge rate and burst/normal modes.


Keytek Series 2000 Features:

  • Continuously selectable voltage from 0 to 25kV, positive and negative
  • Interchangeable discharge networks, current injection adapters & tips for ESD testing to multiple standards
  • Contact mode and air discharge testing including auxiliary adapters for air discharge generation & all five of its basic components
  • Single-shot or programmable repetitive operating modes
  • Hand-held or tripod-mounted

Available Networks for Keytek Series 2000:

  • DN-10 Discharge Network: IEC 61000-4-2 human-body-model Discharge Network (150 pF/330 Ω).
  • DN-1 Discharge Network: IEC human-body-model Discharge Network (150 pF/150 Ω). **
  • DN-2 Discharge Network: NEMA Part DC33 and MIL STD 883E Discharge Network (100 pF/1500 Ω)
  • DN-3 Discharge Network: Upper/lower-body-model Discharge Network (700 pF/100K/150 pF/150 Ω)
  • DN-4 Discharge Network: Segmented-body-model Discharge Network (700 pF/100K/150 pF/150 Ω/20 pF-50 Ω)
  • DN-6 Discharge Network: Optimum basic human-body-model network: EIA Std, PN-1361 (Draft 6, 1985) Discharge Network (100 pF/500 Ω)

** DN-10 may be substituted directly for DN-1; IEC Contact Mode module, CIA-V (for use with DN-10) may be directly substituted for DN-6 and HT-10/DT-4.

Product form

In Stock  In Stock
Monday to friday we offer next day delivery if the product is on stock and exceptions on holidays.

Request Lead Time
Equipment comes and goes everyday, we aren't automated for this website, contact us for status.

International
Depending on where you’re located, we offer next day delivery. Check your status on this link

$2,950.00

      Application/Order Support: 800.794.0349

    Available Mon-Fri 8:00 am to 5:00 pm PST

    • Guaranteed secure & safe checkout.

      <p>Guaranteed <b>secure & safe</b> checkout.</p>
    • Shipped today? Order within: Aug 22, 2025 17:00:00 -0700

    Description

    The KeyTek Series 2000 hand-held or tripod-mounted ESD simulation test system provides a combination of performance characteristics that enable users to test to various ESD standards including IEC, ANSI, SAE and MIL-STD. Interchangeable discharge networks, current injection adapters, and tips (bundled or stand-alone) all plug directly into the discharger’s barrel, and facilitate testing to a broad range of ESD test methodologies to help users achieve market and company-driven quality objectives, and regulatory standards.

    The basic system is comprised of two interconnected units: the ESD-1 Discharger (or gun) that may be either hand-held or tripod mounted, and its associated Power Supply/Control Unit PSC-1. The ESD-1 Discharger contains a basic handle, polarity switch, high voltage set knob, a Digital Stored Voltage Monitor (DVM), and an audible discharge monitor that informs user when a discharge has occurred. The Power Supply/Control Unit includes selectors for repetition rates, charge rate and burst/normal modes.


    Keytek Series 2000 Features:

    • Continuously selectable voltage from 0 to 25kV, positive and negative
    • Interchangeable discharge networks, current injection adapters & tips for ESD testing to multiple standards
    • Contact mode and air discharge testing including auxiliary adapters for air discharge generation & all five of its basic components
    • Single-shot or programmable repetitive operating modes
    • Hand-held or tripod-mounted

    Available Networks for Keytek Series 2000:

    • DN-10 Discharge Network: IEC 61000-4-2 human-body-model Discharge Network (150 pF/330 Ω).
    • DN-1 Discharge Network: IEC human-body-model Discharge Network (150 pF/150 Ω). **
    • DN-2 Discharge Network: NEMA Part DC33 and MIL STD 883E Discharge Network (100 pF/1500 Ω)
    • DN-3 Discharge Network: Upper/lower-body-model Discharge Network (700 pF/100K/150 pF/150 Ω)
    • DN-4 Discharge Network: Segmented-body-model Discharge Network (700 pF/100K/150 pF/150 Ω/20 pF-50 Ω)
    • DN-6 Discharge Network: Optimum basic human-body-model network: EIA Std, PN-1361 (Draft 6, 1985) Discharge Network (100 pF/500 Ω)

    ** DN-10 may be substituted directly for DN-1; IEC Contact Mode module, CIA-V (for use with DN-10) may be directly substituted for DN-6 and HT-10/DT-4.
